This product has been discontinued and removed from our shelves.
SGJS self priming jet pump has high head, and it is suitable for clean water without abrasive particles. This product is applicable for water lifting, domestic use, irrigation for garden and farmland, water distribution with small or medium pressure sets, etc. In addition, it should be installed in enclosed place, otherwise, it should be protected against harsh weather at least.
Hydraulic Performance Curve
Technical Parameters
Materials
1. Pump body: Stainless steel
2. Motor bracket: Aluminum
3. Impeller: POM
4. Shaft with rotor: Stainless steel or CS45#
5. Ejector: POM
6. Mechanical seal: Silicon carbide-graphite
7. Copper winding
Working Conditions
1. Suction height: Up to 9 meters
2. Liquid temperature: Up to 40℃
3. Ambient temperature: Up to 40℃
4. Max. working pressure: 6 bar
Motor
1. 2-pole induction motor
2. Protection rating: IP44
3. Insulation class: B
4. Single-phase with capacitor and thermal overload protection
As a professional self priming jet pump manufacturer and supplier in China, SHIMGE provides a wide array of products, including self-priming peripheral pump, multi-stage deep well submersible pump, single stage single suction vertical/horizontal centrifugal pump, and more.
Related Names: Liquid Ejector Pump | Liquid Jet Pump
