QB peripheral pump is mainly composed of motor, water pump and sealing parts. The motor is single phase asynchronous type, and the brass impeller has peripheral structure. The single mechanical seal using ceramic/graphite/nitrile butadiene rubber works as the motive seal, and oil resistant rubber ring is used as the static seal for rabbet.

This machine has compact and reasonable structure, and the integration of motor and water pump is achieved. Our product has small volume and light weight, and the power varies from 0.37kW to 0.75kW. The maximum flow and head ranges are 1.6~3m3/h and 33~60m, respectively. In addition, clean water without impurities, and other non-corrosive liquids are applicable. Based on these properties, this peripheral pump is used for sprinkling irrigation for garden, pressurizing for household pipeline, etc.

Hydraulic Performance Curve

Technical Parameters

1. Pump body: Cast iron
2. Motor bracket: Aluminum
3. Impeller: Brass
4. Shaft with rotor: Stainless steel or CS45#
5. Mechanical seal: Ceramic-graphite
6. Copper winding

Working Conditions
1. Suction height: Up to 8 meters
2. Liquid temperature: Up to 40℃
3. Ambient temperature: Up to 40℃
4. Max. working pressure: 6 bar

1. 2-pole induction motor: 50Hz
2. Protection rating: IP44
3. Insulation class: B
4. With capacitor and thermal overload protection

SHIMGE is a professional peripheral pump manufacturer and supplier in China. We also provide cast iron submersible sewage pump, self priming jet pump, 6" deep well pump, variable speed circulation pump, among others.
